This two-hour rated shaftwall assembly, designated under UL U415 System B, extends to 10 feet above finished floor. The framing consists of 4-inch 20-gauge minimum C-H metal studs spaced at 24 inches on center with 3.5-inch insulation placed between the studs. One-inch gypsum board liner panels are installed on one side, while two layers of 5/8-inch gypsum board are applied to the opposite side.
2 HOUR RATED (UL U415 SYSTEM B) SHAFTWALL ASSEMBLY: 1" GB LINER PANEL AND TWO LAYERS 5/8" GB ON 4" 20 GA MIN C- H METAL STUDS @ 24" O.C. 3-1/2" INSULATION BETWEEN STUDS. ASSEMBLY TO 10'-0" AFF. TYPE 4S2
