A-3KQ2F — GF Column - 8, D (East Stair)

Architectural · A-3KQ2F

GF Column - 8, D (East Stair)

Scale: 1 1/2" = 1'-0"
Units: imperial
Sheet: A5.06
Discipline: Architectural

Elements

Bracing Columns Stairs

Connections

Bracing Connection

Text on the drawing

D D 8 8 S4 2 3 S1A 0 3 S1A 0 3 S5A 2 33 7" 7" 1' - 1" STAIR S170 WOMEN'S RESTROOM 171 HALLWAY H180 ALIGNMENT OF BRACE FRAME BELOW 2 HR 2 HR
