A cold pipe vent penetrates the roof structure through an 8-inch 18-gauge sleeve fastened to the roof structure. The roof system and insulation assembly, providing a minimum of R-20 insulation, supports a flexible flashing adhered and sealed per manufacturer specifications. A flexible membrane boot fits over the vent pipe with a stainless steel collar tie set in sealant. The perimeter is finished with termination sealant and a stainless steel clamp caulked per manufacturer recommendations.
T/O ROOF STRUCTURE COLD PIPE VENT - SEE MECHANICAL SS CLAMP & CAULK PERIMETER PER MFR TERMINATION SEALANT STAINLESS STEEL COLLAR TIE SET IN SEALANT FLEXIBLE MEMBRANE BOOT FLEXIBLE FLASHING - ADHERE & SEAL PER MFR SPECS VERIFY 8" 18 GA SLEEVE, FASTEN TO STRUCTURE ROOF SYSTEM & INSULATION (MIN. R-20)
