This assembly shows a pipe penetrating a concrete wall, secured by a square mounting plate. The plate is sealed against the concrete surface using a continuous bead of sealant. The pipe-to-plate connection is finished with a continuous weld around the circumference of the pipe. The assembly is identified by reference codes 07 4213.19.A, 07 9200.A, and 07 4213.19.B, with specific pipe identifiers 7-21 and 23-05.
