Hollow metal door featuring a half lite vision panel and standard hardware placement dimensions. The door elevation indicates a maximum hardware height of forty-three inches and a finished height of thirty-eight inches. Detail reference callouts direct to associated architectural sheets for further frame and glazing specifications.
K HOLLOW METAL DOOR W/HALF LITE 4 AD-5 4 AD-5 43" MAX. 38". 1
