A-3HFZZ — Parapet Cap @ 4th Fl Roof-South

Architectural · A-3HFZZ

Parapet Cap @ 4th Fl Roof-South

Scale: 3" = 1'-0"
Units: imperial
Sheet: A7.32
Discipline: Architectural

Materials

Brick Cold-formed Steel Metal (misc.)Timber / Wood

Elements

Facades / Cladding Insulation Parapets Roofs Waterproofing / Flashing

Text on the drawing

472' - 4 3/4" 6" EW9 EW9 T.O. FRAMING / BRICK HEAVY GAUGE SHEET METAL PARAPET CAP SAM. LAP OVER BRICK AND FCS WOOD FURRING WOOD FURRING 3" 4 1/2" WRB FCS 2X WOOD FURRING TRACK 3/4"

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
