A typical cold-formed metal stud connects to a bottom track of size and gauge as required. An end clip of size and gauge as required secures the stud to the track and is fastened with welds as indicated. A concrete slab or foundation supports the track assembly using a fastener as required.
AS REQUIRED AS REQUIRED TYPICAL STUD, SIZE AND GAGE AS REQUIRED END CLIP, SIZE AND GAGE AS REQUIRED TYPICAL TRACK, SIZE AND GAGE AS REQUIRED FASTENER AS REQUIRED
