This isometric architectural detail shows a two-foot-two-inch low wall featuring a sloped top cap finished with a painted wood cap and wall carpet on the face. A rubber base is notched to fit precisely at the flooring transition strip adjacent to the edge of the stair riser. An aisle light is coordinated with mechanical, electrical, and plumbing engineering documents.
RUBBER BASE NOTCHED TO FIT AT FLOORING TRANSITION STRIP EDGE OF RISER RUBBER BASE FLOORING TRANSITION STRIP AISLE LIGHT, SEE MEP PAINTED WOOD CAP 2'-2" LOW WALL WITH SLOPED TOP CAP WALL CARPET
