A curtain wall vertical mullion is flanked by spandrel glass panels and aluminum panels, featuring an alignment angle attached to the mullion. Impaling pins secure insulation materials in conjunction with firestop details referenced on sheet INS-01B. A backer rod and joint seal designated as SE-03 are positioned at the exterior joint centerline.
L C IMPALING PIN, SEE FIRESTOP DETAILS INS-01B CURTAIN WALL VERTICAL MULLION ANGLE ATTACHED TO MULLION, SEE FIRESTOP DETAILS SE-03 AND BACKER ROD SEE FIRESTOP DETAIL SEE FIRESTOP DETAIL INS-01B SPANDREL GLASS PANEL ALUM PANEL 3"
