A concrete stair curb transitions against a vertical concrete wall with a continuous waterproofing membrane running underneath the upper paving slab. A granular base layer supports the lower concrete slab while an expansion joint material separates the concrete elements. The assembly integrates flashing and sealant joints to manage moisture infiltration at the stair landing transition.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
Start membership
