Structural · A-3D3NG

Column Cap Pin and Sleeve Connection at Grid 13

About this detail

A column cap pin and sleeve connection assembly is located at grid line 13, set at an elevation of 124'-5". A central pin connected per detail 4/3.S-528 is fitted into a sleeve detailed per 3/3.S-528. The sleeve is welded to the column web with 3/16 inch welds under SFRS-DC requirements. A cap plate, sized per detail 5/3.S-528, seats on the column per plan and connects to the sleeve with 3/16 inch welds and an 1/8 inch gap joint.
