A stainless steel cable rail with a two-inch steel bar stanchion connects to a cut C12x20.7 steel channel stringer welded to a steel plate. The assembly includes a steel closure plate at the edge of the slab, with the stanchion welded directly to the steel plate. An underlying hollow structural section beam sits in the stair well and coordinates with the structural drawings. Dimensions indicate a six and one-half inch clearance from the edge of the slab plan.
STAINLESS STEEL CABLE RAIL STEEL CLOSURE PLATE AT EDGE OF SLAB; REFER TO STRUCTURAL DRAWINGS FOR MORE INFORMATION CUT C12X20.7 STEEL CHANNEL STRINGER WELDED TO STEEL PLATE 2" STEEL BAR STANCHION REFER TO EDGE OF SLAB PLAN WELD STANCHION TO STEEL PLATE HSS BEAM IN STAIR WELL; REFER TO STRUCTURAL DRAWINGS 612"
