A pigtail wire anchor with a two-inch diameter loop and four-inch tail is placed inside the corrugation of a four-inch typical metal deck with fireproofing. A number three reinforcing bar measuring four feet long is required at the wire loops. Lateral bracing wires and hanger wires connect to the assembly. Refer to sheets A9.4.11 through A9.4.13 for other wire attachment details.
4" TYP METAL DECK WITH FIREPROOFING, W.O., TYP PLACE PIGTAIL INSIDE CORRUGATION PIGTAIL W/ 2" DIA LOOP AND 4" TAIL, TYP #3 REBAR x 4'-0" LONG, REQUIRED AT WIRE LOOPS HANGER WIRE LATERAL BRACING WIRES NOTE: REFER TO A9.4.11 THRU A9.4.13 FOR OTHER WIRE ATTACHMENT DETAILS
