An accessible parking sign mounting assembly consists of a reflectorized aluminum sign panel supported by a two-inch by two-inch fourteen-gauge perforated galvanized steel post. The sign features a blue background approximating Federal Standard 595C color FS 15090 with a white border, the international symbol of accessibility, and two-inch high white lettering indicating minimum fine details. A supplemental van accessible plaque is provided below the main sign panel at van stalls only. Mounting height requirements specify a minimum of five feet zero inches at wall mounted locations and six feet eight inches minimum at post mounted locations above concrete paving.
1' - 2" 1' - 6" 7" PROVIDED AT VAN STALL ONLY 2" HIGH LETTERING, TYP COLOR: WHITE 5'-0" MIN @ WALL MTD 6'-8" MIN @ POST MTD PROVIDE 2"x2"x14GA PERFORATED GALV STEEL POST. SEE DETAIL 3/AS711 REFLECTORIZED ALUMINUM SIGN COLOR: BLUE W/ WHITE BORDER NOTE, BLUE BACKGROUND SHALL APPROXIMATE FS 15090 IN FEDERAL STD 595C INTERNATIONAL SYMBOL OF ACCESSIBILITY PER 2022 CBC 11B-703.7.2.1 COLOR: WHITE MINIMUM FINE $250 VAN ACCESSIBLE SCALE: 1 1/2" = 1'-0" 7 CONCRETE PAVING CONCRETE PAVING
