An Ezy Jamb profile metal door frame is set within a framed partition wall as scheduled on floor plans. An additional layer of gypsum board is applied to establish a reveal, and paper tape and mud finish are applied over the door jamb flange on all typical sides. The door leaf meets the frame header assembly.
EZY JAMB PAPER TAPE AND MUD OVER DOOR JAMB FLANGE ALL SIDES, TYP. DOOR, SEE SCHEDULE PARTITION AS SCHEDULED, SEE FLOOR PLANS ADDITIONAL LAYER OF GYP. BD. TO SET REVEAL IN
