A continuous hydraulic grout bed of one-quarter-inch minimum thickness supports the steel anchor plates embedded within the concrete fill. The rail assembly secures to the slab using three-eighths-inch Hilti KB-TZ expansion anchors with a minimum embedment of two and one-half inches. Anchor plates measure two by seven by one-eighth inches and are spaced at nine inches on center. The surrounding floor incorporates carpet with allowance for required floor covering thickness.
CONC. FILL RAIL (BY SPACESAVER) CONTINUOUS HYDRAULIC GROUT -1/4" MIN. 2-3/8" HILTI KB TZ EXPANSION ANCHORS (MIN. EMBED.-2 1/2") ANCHOR PLATE CARPET - ALLOW FOR FLOOR COVERING THICKNESS AS REQUIRED NOTE: 1. ANCHOR PLATES 9" O.C. 2. ANCHOR PLATE DIMENSIONS: 2"x7"x1/8" 7" 9 1/2" 3/4" 3/4" 2" MIN.
