A-37Y4J — Roof at Foot of Terrace Column

Architectural · A-37Y4J

Roof at Foot of Terrace Column

Scale: 3" = 1'-0"
Units: imperial
Sheet: A7.34
Discipline: Architectural

Materials

Membrane / Roofing Stainless Steel Steel

Elements

Anchors / Embeds Columns Connections / Plates Decks Roofs Waterproofing / Flashing

Connections

Bolted Connection

Text on the drawing

SS CLAMP SS STORM COLLAR FIELD WRAP MEMBRANE FLASHING FASTENER AND PLATE (4) MIN TERRACE COLUMN PER STRUCTURAL SEALANT SEALANT PER ROOFING MFR 1" MEMBRANE FLASHING MEMBRANE ROOFING ADJUST FLASHING LENGTH TO TERMINATE BELOW TERRACE FINISH ROOF PAVER SYSTEM ATTACHMENT PER STRUCTURAL 8"
