A-35JGN — Plan Detail Room 150

Architectural · A-35JGN

Plan Detail Room 150

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Cold-formed Steel Gypsum / Drywall Metal (misc.)Timber / Wood

Elements

Floors / Slabs Partitions Walls

Text on the drawing

EXTEND GYPSUM BOARD B ACOUSTIC WALL ASSEMBLY, RE: FLOOR PLANS WALL ASSEMBLY, RE: FLOOR PLANS 5/8" GYPSUM BOARD 3 5/8" METAL STUD 5/8" PLYWOOD BLOCKING

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
