A suspended ceiling 4-way seismic expansion joint accommodates lateral movement across a one-inch gap between a field-cut main tee and an adjacent main tee and cross tee. A 4-way seismic expansion joint clip with a fastener secures the connection to the main tees. A tee-face sleeve spans across the joint opening below the tees. One side of the splice cap is crimped to allow movement only on the opposite end.
MAIN TEE 4-WAY SEISMIC EXPANSION JOINT CLIP FASTENER FIELD CUT MAIN TEE CROSS TEE TEE-FACE SLEEVE ONE SIDE OF SPLICE CAP CRIMPED TO ALLOW MOVE- MENT ONLY ON OPPOSITE END 1"
