A typical cold-formed metal stud is connected to a track of size and gauge as required, secured to the substrate with a fastener as required. An end clip of size and gauge as required ties the stud web to the track assembly. All component sizes, gauges, and fastener types are provided as required by structural engineering specifications.
AS REQUIRED AS REQUIRED TYPICAL STUD, SIZE AND GAGE AS REQUIRED END CLIP, SIZE AND GAGE AS REQUIRED TYPICAL TRACK, SIZE AND GAGE AS REQUIRED FASTENER AS REQUIRED
