A drop-in roof panel bears against a vertical wall assembly utilizing a 1 1/4" by 1 1/4" 20-gauge stainless steel angle support secured with plywood backing. The wall section extends down to an existing floor over a floor panel, with 4 inches of clearance noted and a layer of 1/4" leveling sand by others. Exterior grade conditions feature 2 inches of mandatory backfill by others at an 8-inch vertical dimension. Vertical spacing between the roof panel and floor assembly measures 82 1/2 inches.
SECTION O2 - O2 82 1 2 " 2" 8" 4" ROOF PANEL DROP IN ROOF 1 1/4" x 1 1/4" 20 GA STAINLESS PLYWOOD BACKING STEEL ANGLE EXISTING FLOOR FLOOR PANEL 2" MANDATORY BACKFILL REQUIRED (BY OTHERS) 1/4" LEVELING SAND (BY OTHERS)
