Rubber floor tile planks and resilient sheet flooring are adhered to a three-eighths-inch concrete slab using adhesive provided by the luxury vinyl tile contractor. A Johnsonite adaptor transition strip bridges the joint between the rubber floor tile and the resilient sheet flooring. The assembly maintains a three-eighths-inch total thickness.
RESILIENT SHEET FLOORING CONCRETE SLAB ADHESIVE BY LVT CONTRACTOR 3/8" JOHNSONITE ADAPTOR - CXX-XX, SEE SPECIFICATION RUBBER FLOOR TILE PLANK
