A plastic pipe of varying type penetrates a fire-rated gypsum board and metal stud partition up to a maximum two-hour rating under UL system W-L-2002 or equivalent. An intumescent wrap strip is installed around the pipe and secured with a hose clamp, with overlap determined by the rated assembly requirements. A pipe collar attaches to the rated partition as required by the assembly. Fire-rated sealant is applied at the penetrations, and fiberglass insulation is installed as scheduled.
6" 3" RATED PARTN AS SCHED VARIES PIPE COLLAR, ATTACH TO RATED PARTN AS REQ'D BY RATED ASSEMBLY INTUMESCENT WRAP STRIP FIBERGLASS INSUL, AS SCHED PLASTIC PIPE (TYPE VARIES) FIRE RATED SEALANT GYPSUM BOARD AND METAL STUD PARTITION RATING NO: MAX 2 HR, UL W-L-2002, OR EQ HOSE CLAMP OVERLAP AS REQ'D BY RATED ASSEMBLY
