A 4 1/2-inch by 2-inch storefront frame supports 1/4-inch clear glazing at the window head. A bent plate matches the window framing. A 3/4-inch by 5 1/2-inch painted hardwood sill is installed at the head, with an identical painted hardwood sill shown beyond.
3/4" x 5 1/2" PAINTED HARDWOOD SILL 1/4" CLEAR GLAZING 4 1/2" x 2" STOREFRONT FRAME 1/4" CLEAR GLAZING 3/4" x 5 1/2" PAINTED HARDWOOD SILL (BEYOND) BENT PLATE TO MATCH WINDOW FRAMING. SCALE: 3" = 1'-0" C3 WINDOW HEAD DETAIL @ CMU
