A-2VKG2 — Elevator Pit

Architectural · A-2VKG2

Elevator Pit

Scale: 1/4" = 1'-0"
Units: imperial
Sheet: A5.04
Discipline: Architectural

Materials

Concrete Metal (misc.)Steel

Elements

Drainage Floors / Slabs Foundations / Footings Stairs

Text on the drawing

C C D D 5 5 7 A5.04 7 A5.04 STEEL ACCESS LADDER SUMP PIT WITH GALVANIZED STEEL GRATE SEE SLAB PLAN FOR SLAB SPOT ELEVATIONS SEE STRUCTURAL SEE STRUCTURAL
