An aluminum curtain wall system intersects with a concrete over metal deck floor assembly at the third floor level. Weathered Cor-ten panels over steel framing extend across the exterior face of the assembly. Perimeter firesafing with a metal angle seals the slab edge at the interface. The concrete slab is sloped to drain.
H-1 THIRD FLOOR 27'-0" EXTERIOR INTERIOR CONCRETE OVER METAL DECK, SLOPE CONCRETE TO DRAIN PERIMETER FIRESAFING WITH METAL ANGLE ALUMINUM CURTAIN WALL SYSTEM WEATHERED CORTEN PANEL OVER STEEL FRAMING EXTENSION AH12.4c 2 AH12.3g 23
