A roof access ladder assembly is anchored adjacent to a cross-laminated timber roof edge and insulated wall construction. The ladder features twenty-six point seven millimeter outside diameter galvanized round hollow structural section rungs spaced at three hundred millimeters on center, supported by galvanized steel angles on both sides and safety grating with checker plate nosings at the landing. Galvanized flat plates measuring seventy-six by ten millimeters and galvanized wall supports are welded to the steel hollow structural section posts concealed within the wall assembly and bolted directly to the glulam beam. Waterproofing membranes including self-adhered membrane and polymethyl methacrylate extend one hundred millimeters onto the steel penetration complete with a leading edge sealant. A note instructs the contractor to confirm if adequate space is provided to install the roofing.
W 76 x 10 GALVANIZED FLAT PLATES EXTEND S.A.M. & PMMA 100mm ON TO STEEL PENETRATION C/W WITH LEADING EDGE SEALANT GALVANIZED WALL SUPPORTS WELDED TO HSS POST IN WALL 11.127 T/O LADDER LANDING 500 1070 8.400 T/O CLT ROOF 300 2727 725 225 CL CONTRACTOR TO CONFIRM IF THIS IS ENOUGH SPACE TO INSTALL ROOFING 172 300 300 300 300 300 300 300 MAX. 150 610 x 610 x 50 CONCRETE PAVER ON PEDESTALS 26.7mm OD GALVANIZED ROUND HSS RUNGS 300mm O.C. EXTEND S.A.M. & PMMA 100mm ON TO STEEL PENETRATION C/W WITH LEADING EDGE SEALANT BOLT WALL SUPPORTS TO GLULAM BEAM GALVANIZED STEEL ANGLES ON BOTH SIDES GALVANZIED MCNICHOLS SAFETY GRATING WITH CHECKER PLATE NOSINGS 160 430 STEEL HSS POST IN WALL (SEE STRUCT.)
