A-2NTSX — Stair Landing Detail

Architectural · A-2NTSX

Stair Landing Detail

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A-563
Discipline: Architectural

Materials

Cold-formed Steel Concrete Gypsum / Drywall Metal (misc.)Timber / Wood

Elements

Text on the drawing

7 A4 A-401 CORNICE. SEE TRIM SCHEDULE ON SHEET A-622, T42 CORNICE. SEE TRIM SCHEDULE ON SHEET A-622, T40 3 5/8" METAL STUD 5/8" GYPSUM BOARD RUNNER TRACK 5/8" GYPSUM BOARD 2 1/2" METAL STUD 1" GYPSUM BOARD CONCRETE FILLED METAL PAN STAIR 6" METAL STUD, EXTERIOR WALL. RE: STRUCTURAL DRAWINGS CARPETING ON STAIR SEE FINISH PLANS
