A canopy frame extends outward from a concrete tilt-up wall, supported by hollow structural section members and a primary structural outrigger. The assembly features twenty-six gauge sheet metal flashing set in mastic and painted to match the building field color. A 3form Koda XT Ghost Panel is mounted perpendicular to the framing using stainless steel standoff mounts. The two-by-two inch hollow structural section members are tilted to achieve a one-quarter inch per twelve inch slope. All welds are ground smooth, sanded, and primed prior to painting.
