A field mold door head assembly integrates a continuous JM TPO membrane adhered to the approved wall substrate and deck. The TPO membrane is secured with JM approved fasteners and plates spaced a maximum of twelve inches on center through the insulation and cover board into the approved deck. A continuous one and a half inch minimum weld is provided where indicated, along with JM edge sealant applied as required. The membrane transitions from the vertical wall surface over a cant strip onto the horizontal roof deck assembly.
INSTALL STOREFRONT GLAZING PER MFG. SPEC STOREFRONT FRAME W/ STOREFRONT DOOR PER PLAN. INSTALL PER MFG 1 1/2" MIN. WELD (CONTINUOUS) JM TPO MEMBRANE ADHERED TO WALL WITH JM APPROVED MEMBRANE ADHESIVE (SEE DETAIL T-FW-M1) CAN'T STRIP JM TPO MEMBRANE ADHERED OR MECHANICALLY FASTENED JM TPO MEMBRANE ADHERED (FOR ADHERED SPECIFICATIONSONLY) JM TPO MEDGE SEALANT IF REQUIRED NOTES: 1. REFER TO JOHNS MANVILLE WEBSITE(WWW.JM.COM) FOR MOST UP-TO-DATE INFORMATION. APPROVED WALL/SUBSTRATE APPROVED DECK JM INSULATION / COVER BOARD 8" MAX. JM APPROVED FASTENER & PLATE 12" O.C MAX. PENETRATION DEPENDANT ON DECK MATERIAL(S). SEE SPECS. INSTALL FIELD MOLD GLAZING PER MFG. SPEC 2x4 ALUMINUM FIELD MOLD FRAME W/ DOOR FIELD MOLD DOOR PER PLAN. INSTALL PER MFG
