The assembly consists of a concrete-filled landing platform supported by a steel stair stringer. The top of the stringer aligns with the landing surface, while the tread geometry is defined by a work point at the intersection of the stringer and the landing edge. The landing platform is specified as 033000 concrete-filled, with vertical dimensions indicating a 3-inch tread rise and a 6-inch depth for the supporting structure below the landing slab.
Text on the drawing
TOP OF STRINGER 033000 - CONCRETE FILLED LANDING PLATFORM 6" 3" 3" 3" TREAD
