Department of Workforce Services Type WD assembly layout and dimensions. Overall width measures 8 5/8 inches with a height of 1'-0 7/8 inches. Vertical dimensions subdivide the face into upper and lower sections with joint spacing. Horizontal dimensions locate internal panel divisions and text placement.
1'-0 7/8" 8 5/8" 4 1/4" 1/2" 3 1/4" 1/2" 8 5/8" 1/2" 3 1/4" 1/2" 1/4" 8 3/8" DEPARTMENT OF WORKFORCE SERVICES TYPE WD
