This assembly features a reinforced membrane secured over rigid insulation and roof sheathing, which is supported by a roof truss. The membrane seam is fastened using a fastener and fastener plate installed per the manufacturer's specifications. The overlap requires a minimum of 1 1/2 inches for the membrane lap and a minimum of 1/2 inch for the fastener plate clearance, with an approximate total seam width of 5 1/2 inches. Sealant is applied at the lap edge to ensure a watertight finish.
Text on the drawing
INSTALL OUTSIDE CORNERS PER DETAIL RIGID INSULATION REINFORCED MEMBRANE CUT-EDGE SEALANT INSTALL PER MANUFACTURER SEAM FASTENING PLATE REINFORCED MEMBRANE BONDING ADHESIVE METAL CAP OR COUNTER FLASHING INSTALL PER MANUFACTURER FASTEN 12" O.C. USE ONE CONTINUOUS SHEET OF REINFORCED MEMBRANE TO WRAP AROUND CURB OR FORM FROM COATED METAL 1 1/2" MIN. 1/2" MIN. 5 1/2" (APPX.) ROOF TRUSS - SEE STRUCTURAL INSTALL PER MANUFACTURER SEALANT FASTENER & FASTENER PLATE, INSTALL PER MANUFACTURER REINFORCED MEMBRANE RIGID INSULATION ROOF SHEATHING, SEE STRUCTURAL
