A 90-degree mitered panel joint between concrete walls incorporates a one-half-inch sealant joint backed by a compressible backer rod. Architectural dimensions reference the corner working point, while structural dimensions govern the wall panel configuration.
SEALANT & BACKER ROD 'B' 90° MITERED PANEL JOINT CONCRETE WALL PER STRUCT. WORKING POINT ARCH. DIM. ARCH. DIM. PER STRUCTURAL 1/2" SEALANT & BACKER ROD
