A split partition wall assembly separates a freezer side and a cooler side, meeting at a roof panel and floor panel over an existing floor. The wall panels are tied together at the top by three-eighths-16 by five-and-a-half-inch long fiberglass threaded rods spaced at twenty-three inches on center, secured on both sides with three-eighths-16 stainless steel hex nuts, three-eighths stainless steel lock washers, and three-eighths-16 stainless steel acorn nuts. One-and-a-half-inch by one-and-a-half-inch aluminum angles are installed on both sides and fastened with number 8 by three-quarter-inch pan head Phillips tek screws at twenty-three inches on center. Beauty trim angles matching the interior metal finish are applied on both sides.
ROOF SUPPORT ANGLE SPLIT PARTITION FLOOR & ROOF 9 16 " 9 16 " 3 7 16 " 3 7 16 " EXISTING FLOOR 3/8-16 S/S HEX NUT (BOTH SIDES) 3/8 S/S LOCK WASHER (BOTH SIDES) ALUM ANGLE (BOTH SIDES) 1 1/2" x 1 1/2" SCREWS @ 23" O.C. (BOTH SIDES) #8 x 3/4" PPH TEK FIBERGLASS THREADED ROD 3/8-16 x 5 1/2" LG @ 23" O.C. 3/8-16 S/S ACORN NUT (BOTH SIDES) ROOF PANEL WALL PANEL COOLER SIDE FREEZER SIDE FLOOR PANEL BEAUTY TRIM ANGLE TO MATCH INT. METAL FINISH (BOTH SIDES)
