A curtain wall head connection at a sliding door entrance is anchored to a hollow structural section support sized per structural drawings. Extruded aluminum fins are attached per the curtain wall manufacturer specifications, paired with matching aluminum flashing. A sliding door system provides a nine-foot clear opening.
F MEZZANINE 73.28' EXTERIOR W. HASTINGS 351 SF VESTIBULE L01-01 4' - 0" EXTRUDED ALUM. FINS PER CW MANUFACTURER HSS, SEE STRUCTURAL 4 1/2" 9'-0" CLR. OPENING ALUM. FLASHING TO MATCH COLOUR OF FINS SLIDING DOOR SYSTEM, SEE DOOR SCHEDULE CW1
