Plastic laminate upper and lower cabinets feature white melamine interiors, wire pulls, and adjustable interior shelving. The lower sink cabinet includes a countertop with a four-inch integral splash, a mitered edge, and designated knee and toe clearances. Continuous wood blocking is installed as required behind the casework, and a locker base is provided by the manufacturer.
WIRE PULL PLASTIC LAMINATE PLASTIC LAMINATE CABINET WITH WHITE MELAMINE INTERIOR ADJUSTABLE SHELVES AT INTERIOR COUNTERTOP WITH 4" INTEGRAL SPLASH AND MITERED EDGE 2'-10" 1'-8" 1'-8" 1'-6" 6" CONTINUOUS WOOD BLOCKING AS REQUIRED LOCKER BASE BY MANUFACTURER WIRE PULL PLASTIC LAMINATE CABINET WITH WHITE MELAMINE INTERIOR LOWER SHELF AND TRIM ATTACHED TO DOORS COUNTERTOP WITH 4" INTEGRAL SPLASH AND MITERED EDGE 2'-10" 1'-8" WIRE PULL PLASTIC LAMINATE CABINET WITH WHITE MELAMINE INTERIOR ADJUSTABLE SHELVES AT INTERIOR 2'-6" 2'-3" 8" 11" 6" KNEE CLEARANCE TOE CLEARANCE 26 27
