A cold-formed steel wall brace consisting of a 600S162-33 stud spaced at twenty-four inches on center connects to an overhead concrete slab on metal deck. Four Hilti DS powder-actuated fasteners with a two-inch embedment anchor the assembly directly into the concrete deck. Four number twelve Tek screws secure the 600S162-33x one-foot six-inch member at the brace location.
(4) HILTI DS POWDER ACTUATED FASTENERS (EMBED = 2") CONCRETE SLAB ON METAL DECK 600S162-33x 1'-6" @ BRACE (4) #12 TEK SCREWS WALL BRACE: 600S162-33 @ 24" OC CONTINUOUS SEALANT BOTH
