Architectural · A-2E8TB

Vierendeel Truss and Tower Curtain Wall Fin Detail

Elements

About this detail

Geometric alignment between a tower curtain wall and an FP-1 architectural fin mounted above a pair of FP-1 Vierendeel truss members. The face of the Vierendeel truss aligns directly with the face of the tower curtain wall, maintaining a two-inch vertical clearance. The fin features a curved radius portion that transitions into a straight portion, governed by specific work points detailed on sheet A373. Horizontal and vertical dimensions of five inches, four inches, one inch, and three inches locate the work points for the front and back edges of the fin. Work points vary across the assembly and require cross-referencing sheet A373 for layout.
