A two-stage floor drain is set into a concrete slab featuring a sloped mortar bed with a maximum two percent slope toward the drain. A slurry bond coat is applied where necessary beneath the sloped mortar bed, which is reinforced with 16-gauge two-inch by two-inch welded galvanized steel mesh. A waterproofing membrane extends beneath the tile mortar bed and ties into the drain housing. LHT or medium bed mortar supports the finish flooring, set over a drainage composite filler and epoxy grout. Silicone sealant and bond breaker tape seal the joint at the drain perimeter.
DRAINAGE COMPOSITE FILLER TWO-STAGE FLOOR DRAIN EPOXY GROUT SILICONE SEALANT AND BOND BREAKER TAPE LHT OR MEDIUM BED MORTAR WATERPROOFING MEMBRANE SLOPED MORTAR BED 16 GA. 2"X2" WELDED GALV. STEEL MESH SLURRY BOND COAT WHERE NECESSARY CONCRETE SLAB SLOPE TO DRAIN, MAX 2%
