A vehicle barrier cable rail assembly is positioned at a sloping post-tensioned concrete structural slab. The system incorporates horizontal cables spaced at four inches typical to satisfy the four-inch sphere rule for pedestrian and vehicular safety. The post-tensioned slab features a two-inch wash and is referenced to the top of the structural slab and bottom of slab elevations. Columns and beams are located beyond the primary assembly plane.
REFERENCE T.O. STRUCTURAL SLAB FACE OF COLUMN BEYOND BOTTOM OF SLAB FACE OF COLUMN BEYOND SSD 2" 3'-6" 6" TYP 4" 3'-8" SLOPING POST TENSIONED SLAB, SSD. FACE OF BEAM BEYOND 6" 2" WASH, TYP. VEHICLE BARRIER CABLE RAIL POST TENSIONED SLAB, SSD. 4" SPHERE
