An 8-inch by 8-inch by 1/2-inch hollow structural section steel column mounts to a base plate secured atop a Level P4 concrete column. The concrete assembly intersects with a post-tensioned concrete slab and a concrete beam below, with cables routed through typical pipe sleeves. A vertical dimension of 3 feet 6 and 1/2 inches spans from the top of the ramp to the top of the guard rail.
LEVEL P4 CONCRETE COLUMN, SEE STRUCTURAL T.O RAMP PER PLAN 05 5000 HSS 8"x8"x1/2" COLUMN, SEE STRUCTURAL PER PLAN 3' - 6 1/2" 05 5000 BASE PLATE, SEE STRUCTURAL CONCRETE BEAM, SEE STRUCTURAL CONCRETE PT SLAB, SEE STRUCTURAL SLOPE RUN CABLE THROUGH PIPE SLEEVES, TYP. T.O GUARD RAIL
