An aluminum cover plate is secured over a wall corner using a mounting bracket fixed with two stainless steel long pan-head self-drilling screws. The mounting bracket holds the curved corner guard element at a scheduled height with specified 1 1/2 inch spacing. A head screw with a Phillips head slot fastens the assembly through the partition material. All components coordinate to provide robust corner protection for interior walls.
COVER PLATE 1 1/2" 1 1/2" 1 1/2" 4 1/2" SCHEDULED HEIGHT MOUNTING BRACKET LONG PPH SELF DRILLING SCREW SS. (2) PER BRACKET HEAD SCREW W/PHILLIPS HEAD SLOT
