The assembly is supported by primary structural steel framing protected with two-hour rated spray-on fireproofing. A three-and-five-eighths-inch metal stud (362S162-54) and track at sixteen inches on center forms the cold-formed steel framing. A base plate and anchor bolt secure the stair stringer to the landing. Gypsum board continues below the stair tread to form the ceiling finish.
STAIR STRINGER 3 5/8" METAL STUD - 362S162-54 & TRACK 16 GA @ 16" O.C. STEEL FRAMING, SSD CONTINUE GYP. BD. BELOW STAIR TREAD BASE PLATE & ANCHOR BOLT, S.S.D. 2-HR RATED SPRAY-ON FIRE PROOFING ON PRIMARY STRUCTURAL MEMBERS MAIN LANDING
