A weak-axis steel girder connection at a column per plan utilizes a three-eighths-inch typical shear tab plate welded with five-sixteenths-inch fillet welds. Two three-quarter-inch diameter erection bolts with standard slotted holes are provided in the beam and shear tab typical. Diagonal bracing members connect via one-half-inch and three-eighths-inch gusset plates welded to the structural framing with five-sixteenths-inch fillet welds and complete joint penetration welds designated for seismic force-resisting systems. Additional notes specify beam top and bottom beam guide configurations and required clearances.
RAE 02 120' - 4 13/16" 9 7 3.S-327 1' - 1 1/2" 1' - 2 1/2" GUSSET PL 1/2" 1 1/2" 3" 3" 1 1/2" 1 1/2" 3 1/2" (2) 3/4" DIA ERECTION BOLTS, SSL IN BEAM AND TAB, TYP MEMBER PER PLAN GUSSET PL 3/8" R CJP, SFRS, BG T&B, TYP GIRDER PER PLAN GIRDER PER PLAN 5/16 5/16 SFRS MT MT 5/16 5/16 SFRS COL PER PLAN SHEAR TAB 3/8" PL, TYP 3/16 5/16 4 3.S-327 WEAK AXIS GIRDER CONNECTION 11" MIN 5" MIN
