The cyclone collection box plan view lays out the structural and functional penetrations including a six inch inlet flange connection to a grit washer and a blind flange. Access is provided via a compression latched cleanout with handle, complemented by an overflow sensor typically positioned on top. Overall unit dimensions span five feet five and one half inches by two feet three inches, featuring eight five-eighths by one and one-quarter inch slots for mounting or connection.
COMPRESSION LATCHED CLEANOUT WITH HANDLE 10 1/2" 5' - 5 1/2" 6" 2' - 3" 8X 5/8 X 1 1/4 SLOT 5 - 4 - CYCLONE CONNECTION (TYP) OVERFLOW SENSOR (TYP) 1 BLIND FLANGE (TYP) 6" INLET FLANGE CONNECTION TO GRIT WASHER
