Twelve-gauge hanger wires support main runners and cross runners of an acoustic ceiling suspension grid, secured with a minimum of three tight turns at the end condition. Acoustic panels bear on the grid system with cross runners spaced at a maximum of eight inches. Two nails at the end of horizontal struts are placed with the nail head toward the centerline of the span of the strut.
8" MAX. WIRE HANGER 12 GA. MIN. 3 TIGHT 1 1/2" TURNS IN FOR END CONDITION, SEE 4/A9.53 FOR SUSPENSION SYSTEM, SEE 8/A9.53 ACOUSTIC PANEL CROSS RUNNER MAIN RUNNERS WITH NAIL HEAD TOWARD CENTERLINE OF SPAN OF STRUT. (2) NAILS AT THE END OF HORIZONTAL STRUTS ARE TO BE PLACED (1) 1/4 OF THE LENGTH OF THE END RUNNER WHICHEVER IS LESS. NOTES:
