A quarter-inch thick stone countertop rests on a substrate with an edge overhang detailed above cabinet doors and drawers. Vertical dimensions indicate a one and sixty-one one-hundred-twenty-eighths inch edge drop condition.
AT STONE SURFACE CABINET DOOR/DRAWER WHERE OCCURS DIM PT DIM PT 1 61/128" 1/4" STONE COUNTERTOP
