A-26E2K — Vertical Plenum Plan Detail

Architectural · A-26E2K

Vertical Plenum Plan Detail

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A-555
Discipline: Architectural

Materials

Cold-formed Steel Gypsum / Drywall Metal (misc.)Steel Stone Timber / Wood

Elements

Bracing Insulation Partitions Walls

Connections

Bracing Connection

Text on the drawing

STONE 2" INSULATED WALL SHEATHING 2" SPRAY FOAM INSULATION 6" METAL STUD STRUCTURAL STEEL FRAME 3 5/8" METAL STUD 5/8" TYPE X GYPSUM BOARD. SMOKE SEAL ALL EDGES/GAPS WITH FIRE CAULKING INTUMESCENT PAINT PLENUM RATED DUCT LINER EXTERIOR 48" @ PASS THROUGH 38" @ CELESTIAL ROOM +/- 1'-0" D3 A-555 D3 A-555

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
