Lateral force bracing configuration featuring main beams intersecting with cross tees and supported by twelve gauge splayed brace wires positioned at an angle of forty-five degrees or less. The vertical strut member connects at the intersection to provide seismic stability for the suspended ceiling system.
45° or less 45° or less 45° or less 45° or less figure 2 Lateral force Bracing Main beam Cross Tee 12 gage splayed brace wires figure 3 Maximum Recommended Lengths for Vertical Struts
